Elco-E2L13F27W
Couldn't load pickup availability
10.5 - 12.5W, 2700K - SunsetK, 800 - 1000 lm - 850 - 1100 lm
The Teak™ LED light engine is an IC Rated diecast construction specification grade 2″ LED downlight. Boasting an output up to 1100 lumens - more than a traditional 75W MR16 halogen lamp. Style options, beam options and color finish options offer maximum flexibility in design. Drivers and housings are specified separately for maximum flexibility per your project’s needs. The patented engine offers auto release clips that make installation a breeze.
- Dimmable ELV, Triac or 0-10V depending on driver used.
- Same LED light engine for 850 and 1100 lumens (see housings)
- UL Listed for Direct Contact with insulation
- Works with compatible ceilings up to 1¼″
- Height allows for use in ceilings with under 5" depth. Ceiling thickness can be reduced from fixture depth.
- 38° Standard beam with optional 28° and 60°
- Wet Location Rated for Indoor and Outdoor Use
- UL listed, Meets California Title 24 JA8-2016-E and Energy Star standards.
- Life Span 50,000 Hours L70
- U.S. Pat. 10,125,959
Resources & Downloads
Product SKU
| Catalog Number | Lamp type | Wattage | CCT | Lumens | Beam Angle | Finish |
| E2L13F27W | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | White |
| E2L13F30W | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | White |
| E2L13F35W | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | White |
| E2L13F40W | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | White |
| E2L13FSDW | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | White |
| E2L13F27B | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | Black/White |
| E2L13F30B | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | Black/White |
| E2L13F35B | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | Black/White |
| E2L13F40B | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | Black/White |
| E2L13FSDB | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | Black/White |
| E2L13F27BZ | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | All Bronze |
| E2L13F30BZ | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | All Bronze |
| E2L13F35BZ | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | All Bronze |
| E2L13F40BZ | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | All Bronze |
| E2L13FSDBZ | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | All Bronze |
| E2L13F27C | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | Chrome/White |
| E2L13F30C | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | Chrome/White |
| E2L13F35C | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | Chrome/White |
| E2L13F40C | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | Chrome/White |
| E2L13FSDC | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | Chrome/White |
| E2L13F27H | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | Haze/White |
| E2L13F30H | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | Haze/White |
| E2L13F35H | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | Haze/White |
| E2L13F40H | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | Haze/White |
| E2L13FSDH | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | Haze/White |
| E2L13F27BB | LED | 10.5 - 12.5W | 2700K | 850 - 1100 lm | 38° | All Black |
| E2L13F30BB | LED | 10.5 - 12.5W | 3000K | 850 - 1100 lm | 38° | All Black |
| E2L13F35BB | LED | 10.5 - 12.5W | 3500K | 850 - 1100 lm | 38° | All Black |
| E2L13F40BB | LED | 10.5 - 12.5W | 4000K | 850 - 1100 lm | 38° | All Black |
| E2L13FSDBB | LED | 10.5 - 12.5W | SunsetK | 800 - 1000 lm | 38° | All Black |
