Elco - 6" Shallow New Construction IC Airtight Housing

$13.65 USD
$13.65 USD $27.30 USD

ELC-EL760ICA

Voltage
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Overview

The Elco 6" Shallow New Construction IC Airtight Housing is designed for energy-efficient LED lighting installations in insulated ceilings. Its low-profile design makes it ideal for shallow plenum applications. This housing is IC-rated for direct contact with insulation and features airtight construction to reduce energy loss.

Technical Specification

8W

  • IC Airtight for direct contact with insulation.
  • Transformer (EL770ICA-7 only): 277V to 120V step-down transformer.
  • Meets Title 24 requirements. ENERGY STAR® Certified.
  • Trims and inserts sold separately.
Wattage: 8W
Voltage: 120/277V or 277V
Lamp Type: LED
Damp Location: Listed
Elco - 6" Shallow New Construction IC Airtight Housing


Resources & Downloads


Product SKU

Catalog Number Description Lamp type Wattage Voltage
EL760ICA LED 120V
EL760ICA-7 with Step-down Transformer 277V to 120V LED 277V
EL760ICA-EM5 Emergency Battery Backup 8W 120/277V

Additional Information

  • Airtight Construction: Meets ASTM E-283 standards to restrict airflow and improve energy efficiency.
  • IC Rating: Suitable for direct contact with insulation, reducing the need for additional fireproofing.
  • Damp Location Listing: UL listed for damp locations, making it suitable for use in various environments.
  • Title 24 Compliance: Meets California Title 24 energy efficiency requirements when used with compatible LED lamps.
  • Hanger Bars: Pre-installed and adjustable, facilitating easy installation in standard joist spacing.
