Elco ELJ444R ALO Remodel Frame *DISCONTINUED*

$30.73 USD
$30.73 USD $61.46 USD

ELC-ELJ444R

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Overview

The Elco ELJ444R ALO Remodel Frame is designed for use in remodel applications where insulation contact is permitted. This low-profile frame supports Elco's 4" LED modules and trims, providing an airtight seal to reduce energy loss. It is compatible with various ceiling materials and is UL listed for safety and performance.

Technical Specification

*DISCONTINUED*

Maximum 2-Hour Fire Rated ceiling assembly can be maintained when installed according to the International Building Code, Section 714.

  • IC Airtight for direct contact with insulation
  • For use in IC and Non-IC applications
  • Low profile makes ideal in shallow plenum applications
  • Remodel tabs will not be completely covered by trim, painting may be required after installation or use of Oversized Ring (ELJ4OV) to cover tabs
  • UL listed under UL 514A Standards as a metallic outlet box
  • UL listed under 1598 Standards as a luminaire housing
  • Maximum 2-Hour Fire Rated ceiling assembly can be maintained when installed according to the International Building Code, Section 714
  • U.S. Patents 10295163 & 10876721, D892069 & D902160, and other U.S. Patents Pending
Installation Guide - 4” Deep Metallic Outlet Box
Installation Guide - 4” LED Retrofit Kits into 4” Deep Metallic Outlet Box

Product SKU

Catalog Number Description
ELJ444R Remodel Box

Additional Information

  • Designed for remodel applications where insulation contact is permitted.
  • Airtight construction reduces air leakage and improves energy efficiency.
  • Compatible with Elco 4" LED trims and modules.
  • Suitable for both IC and Non-IC applications.
