EMCOD EGP1200P12AC - 1200W 12/24V AC - Indoor/Outdoor Dimmable Magnetic Power Supply - Powder Coated Black Steel
EMCOD EGP1200P12AC - 1200W 12/24V AC - Indoor/Outdoor Dimmable Magnetic Power Supply - Powder Coated Black Steel
EMC-EGP1200P12AC
This product has been discontinued, but we're here to help.
If you were looking for this item, there may be updated or alternative versions available. Our team is happy to provide guidance, suggest compatible options, or answer any questions you have. We're just a call away.
Contact Us
Product Information
Technical Specification
 |
Conforms to UL STD. 2108 |
| Certified to CSA STD. C22.2 № 250.0, |
|
Magnetic Dimmable
Outdoor Black Powder Coated Steel Enclosure
Multi Circuit: 12/24VAC
Total Wattage: 1200W max
Input Voltage: 120V 60Hz
Outdoor Black Powder Coated Steel Enclosure
Multi Circuit: 12/24VAC
Total Wattage: 1200W max
Input Voltage: 120V 60Hz
Transformer
Dimmable with any LV magnetic dimmer as long as you cover dimmer’s
min load.
Temperature class B(130°C)
Two section bobbin completely separated primary and secondary windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 18A
per circuit
Housing
The actual transformer 1200W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 4 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 10.29, W = 6.78, D = 5.62
Weight (LBs): 30
Electrical Parameters
Input Voltage: 120V 60HzMax. input current at full load: 10.5A
Output voltage without load: 12.7/ 25.8VAC
Output voltage fully loaded: 12/ 23.8VAC
Max. Total Wattage: 1200W Max. per circuit: 300W
Max. Output Current: 25/ 12.5A per circuit.
Efficiency: 95%
Load regulation: 5%
