EMCOD - ML20S12DC Transformer - Magnetic LED Driver - 20W - 12VDC
EMCOD - ML20S12DC Transformer - Magnetic LED Driver - 20W - 12VDC
ML20S12DC
Regular price
$47.85 USD
Sale price
$47.85 USD
Regular price
$95.70 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Black Powder Coated Steel Enclosure
 4008104 |
Conforms to UL STD. 1310 |
| Certified to CSA STD. C22.2 № 223 |
|
| model EM20 | |
Transformer
Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on emcod.com Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal self reset primary breaker 0.8A Thermal self reset secondary breaker 3A
Housing
The actual transformer 20W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 2 knockouts sizes for 3/8 inch screw cable connectors Enclosure Temperature does not exceed 65°C at 45°C ambient and fully loaded Dimensions (inch): H = 7, W = 2.11, D = 1.54 Weight (LBs): 1.9
Electrical Parameters
| Input Voltage: | 120V 60Hz |
| Max. input current: | 0.2A at full load |
| Output voltage without load: | 13.2VDC |
| Output voltage fully loaded: | 11.6VDC |
| Max. Total Wattage: | 20W |
| Max. Output Current: | 1.7A |
| Efficiency: | 85% |
