EMCOD - ML50S24DC Transformer - Magnetic LED Driver - 50W - 24VDC

EMCOD - ML50S24DC Transformer - Magnetic LED Driver - 50W - 24VDC

$60.20 USD
$60.20 USD $120.40 USD

EMC-ML50S24DC

Default Title
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Technical Specification

Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure

4008104
 Conforms to UL STD. 1310
Certified to CSA
STD. C22.2 № 223
model EM60

Link to certification

Spec Sheet

Installation Instructions

Transformer

Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal self reset primary breaker 1.5A
Thermal self reset secondary breaker 5A

Housing

The actual transformer 60W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 2 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 7.38, W = 2.11, D = 1.6
Weight (LBs): 0.21


Electrical Parameters

Input Voltage: 120V 60Hz
Max. input current: 0.56A at full load
Output voltage without load: 26.4VDC
Output voltage fully loaded: 23.5VDC
Max. Total Wattage: 60W
Max. Output Current: 2.5A
Efficiency: 85%
