Detail Specifications:
• Finish: White, Custom finishes available
• IP Dating: Damp Location
• Beam Angle: 110°
• Chip: SMD 2835, R9 >50, CRI >80
• 3 Step MacAdam Ellipses
• Operating Temperature: -40° - 114° F
• Lens: PMMA Frosted
• Average life (L70) of 50,000 hours
Applications:
• General Indoor Lighting
• Utility & Storage
• Office and Meeting Rooms
• Education, Healthcare, Retail, Hospitality
• Residential and Commercial
Product Information:
• Aluminum housing finished with corrosion free powder coat
• Even light distribution
• Lightweight for easier installation
• Super slim only 1” thick!
Driver Options:
• 1x1 & 1x2: 120V Triac Dimmable
• 2x2, 2x4, 1x4: 120-277V 0-10V Dimmable
• THD: <15% (=/-5% tolerance), PF >0.9, 50/60Hz
• Isolated Driver
• Flicker Free
Mounting & Installations:
• 3O/4O Junction Box
• Surface mount bracket included
Certifications:
• UL Listed for USA and CA
• 1x1 & 1x2: Energy Star Certified
• 2x2, 1x4, & 2x4: DLC Listed
• Approved for CA T24
• 5 Year Limited Warranty
• FCC CFR 47, GCC Part 15, Subpart B:2017
