Detail Specification:
• Finish: Bronze, Black, White
• IP Rating: Wet Location IP65
• Beam Angle: 60°
• CCT: 30/40/50K Selectable
• Lumens: 3,600
• Chip: SMD 2835, R9 >50, CRI >80
• Operating Temperature: -40° - 122° F
• BUG: B2-U2-G2
• Lens: Clear glass with optics
• Average life (L70) of 50,000 hours
Applications:
• Dock and Loading
• Walkways & Pathways
• Parking Lots
• Hospitality, Multi-Family
• Outdoor Corridors
• General Outdoor Lighting
• Residential, Commercial and Industrial
Product Information:
• Sturdy die-cast aluminum housing finished
with corrosion free powder coat
• Photocell included on each fixture. Easy disconnect.
• 1.5' STJW 18.3 AWG cable whip included • Illuminates up and down and edge
• Select-n-Switch Technology: 3-CCT Selectable + 3-Power Selectable
• Instant-On to full brightness
Driver Options:
• UNV: 120-277V 0-10V Dimmable
• Built in 6Kv Surge Protector
• THD: <20% (+/-5% tolerance), PF >0.9, 50/60Hz
Mounting & Installation:
• Mounts to 3 or 4” J-box
• Covers a standard 4” recessed j-box
Certifications:
• UL Listed for USA and CA
• DLC Listed
• Approved for CA T24
• 5 Year Limited Warranty
• FCC CFR 47, GCC Part 15, Subpart B:2017
