GM Lighting LineDRIVE LD-E-UNV60 60W 12VDC / 24VDC Electronic LED Non-Dimmable Power Supply

GMLighting-LD-E-UNV60

This product has been discontinued, but we're here to help.

If you were looking for this item, there may be updated or alternative versions available. Our team is happy to provide guidance, suggest compatible options, or answer any questions you have. We're just a call away.

Contact Us

Product Information

Overview

The GM Lighting LineDRIVE LD-E-UNV60 is a 60W Class 2 rated electronic LED power supply providing 12VDC or 24VDC output. Designed for select LED fixtures that do not require dimming, this power supply supports both 120V and 277V inputs at 60Hz. Housed in a low-profile powder-coated steel enclosure with four knock-outs for easy installation, it is especially suitable for LTR-S RGBW tape lighting.

Technical Specification

Model
LD-E-UNV60
Input Voltage
120V or 277V ± 10%, 50/60Hz
Output Voltage
12VDC / 24VDC
Power Output
60W
Class Rating
Class 2
Enclosure
Powder-coated Steel, Low Profile
Protection Features
Over voltage protection, Short circuit protection
Certification
UL Listed, FCC Compliant
IP Rating
IP20 for damp location
Dimensions
8.25" L x 4.10" W x 1.56" H

Additional Information

  • Designed for LED fixtures that do not require dimming
  • Includes 4 knock-outs for flexible installation
  • Suitable for damp locations (IP20 rating)
