GM Lighting LineDRIVE LD-MD-UNV150-12 150W 12VDC Magnetic LED Dimmable Power Supply

24V - 120V or 277V/60Hz - Class 2 - Auto Reset

Dimensions: 8.86"L x 3.31"W x 2.89"H

LineDRIVE Series 12VDC / 24VDC Magnetic LED Power Supplies are Class 2 rated and designed to operate with standard MLV dimmers. For vertical mounting only.

Encased in a low profile powder coated steel enclosure that includes 2 knock-outs to enable easy installation, these LineDRIVE power supplies are the perfect choice GM Lighting products.

LineDRIVE Power Supply CROSSOVER GUIDE

LineDRIVE Power Supply QUICK GUIDE

MAGNETIC SPEC SHEET

INSTALLATION INSTRUCTIONS

• Universal Input and Output
• 120V/277V dual input
• 12V/24V output
• Dimmable (MLV)
• Dims down to 5%
• Steel case
• NEMA 3R for outdoor use
• Auto-reset protection for short circuits and over voltage
• 5 year warranty
• ETL for indoor and outdoor use
