GM Lighting NeoVISION24 NV24S-3W-RD-16 16’-4” 24VDC Red SideFlex Neon Tape

Name: GM Lighting NeoVISION24 NV24S-3W-RD-16 16’-4” 24VDC Red SideFlex Neon Tape
Brand: GM Lighting
SKU: GMLighting-NV24S-3W-RD-16
Price: 450.0 USD
Availability: InStock

GMLighting-NV24S-3W-RD-16

Default Title Default Title

Product variants

$450.00 USD

$450.00 USD ~~$900.00 USD~~

Shipping calculated at checkout.

Shop safely

Secure your shopping experience with various safe and trusted payment methods.

Shop safely with us

Catalog No.	Length	Lumens per Foot	CRI	Color Temp.	Max. Run
NV24S-3W-RD-16	16’-4”	128	90+	Red	32’-8”

A 24VDC flexible linear ‘neon’ tape that is field cuttable and joinable. Designed for applications that require ultra-rich light and color saturation that is characteristic of neon. SideFlex enables horizontal bending that conforms tape around curvilinear surfaces.

24VDC operation
3.0 watts per foot
Wet location - IP65
Multiple power feed options
Tape encased in UV stable silicone (UV protected)
Dimmable
3000K or 4000K / Amber, Blue, Green or Red
120° viewing angle
Maximum run: 32’-8”
Field cuttable and joinable in 2 inch increments while retaining IP65
No tools required for capping and joining
Mounting clips included (recommend use 1 per foot)

Power Supply / Transformers Used With This Product

Kelvin temperature (color) ±100K.

Every reel includes (1) NV24S-PF-EF (tape to power feed with 48” of lead.). 16’ reel includes (16) NV24S-MC-A mounting clips and screws. 32’ reel comes with (32) NV24S-MC-A mounting clips and screws. Operating temp.: -4° - 130°F.

NeoVISION24™ SideFlex SPEC SHEET

SALES SHEET

PHOTOMETRICS

INSTALLATION INSTRUCTIONS
