Intermatic ETW3CP Connect 365-Day Programmable Smart Wi-Fi Timer, 120-277 VAC, 2xSPDT, Indoor/Outdoor Plastic Enclosure

Intermatic ETW3CP Connect 365-Day Programmable Smart Wi-Fi Timer, 120-277 VAC, 2xSPDT, Indoor/Outdoor Plastic Enclosure

$339.59 USD
$339.59 USD $475.39 USD

INT-ETW3CP

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Available at 7950 Deering Ave

This item is available and ready.

Check availability at other stores
Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Overview

The Intermatic ETW3CP is a robust 3‑circuit, Wi‑Fi enabled timer designed for year‑round scheduling of lighting, irrigation, pumps, and HVAC systems. It features app-based control, astronomic timekeeping, holiday scheduling, and remote access via the Intermatic Connect platform.

Technical Specification

Model
ETW3CP
Voltage
120–277 VAC, 50/60 Hz
Circuits
3 independent SPDT relays
Max ON/OFF Events
256 events
Holiday Blocks
Up to 64
Min ON/OFF Duration
1 minute
Load Types
LED/Electronic ballast (16 A), General-purpose (30 A NO / 10 A NC), Motor (1 HP @ 120 V, 2 HP @ 240 V)
Enclosure
Plastic, Type 3R (indoor/outdoor)
Dimensions (H×W×D)
7.5″ × 8.875″ × 3″
Memory Backup
EEPROM + CR2032 battery (10 yr backup)
Power Usage
7 W
Temperature Range
–40 °F to 158 °F (–40 °C to 70 °C)
Certifications
cULus, FCC Class A, RoHS, Green Energy +, UL Category III
Spec Sheet
ETW3CP Technical Data Sheet

Additional Information

  • App based configuration and scheduling.
  • Up to 256 set points or events.
  • Up to 64 holiday blocks with schedule capabilities.
  • Automatic input voltage selection from 120 to 277 VAC, 50/60 Hz.
  • Local or remote connectivity.
  • Configurable outputs allow the control of various voltages and applications.
  • Relays incorporate zero-crossing technology to extend the life of the control.
  • Non-volatile EEPROM memory protects programming indefinitely.
  • LED compatible.
