EMCOD - EM150S12DC Transformer - Dimmable LED Power Supply - 150W - 12VDC
EMCOD EM Series - Indoor/Outdoor Series | EMCOD Lighting - LED drivers, Lighting and Transformers | Products |SKU: EM150S12DC
Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Black Powder Coated Steel Enclosure
 4008104 |
Conforms to UL STD. 2108 |
|
Certified to CSA STD. C22.2 № 250.0 |
|
| model EM150 | |
Transformer
Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Two section bobbin completely separated primary and secondary windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 2A
Magnetic manually reset secondary breaker 20A
Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Two section bobbin completely separated primary and secondary windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 2A
Magnetic manually reset secondary breaker 20A
Housing
The actual transformer 150W is encapsulated in the enclosureThe enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8, W = 4.15, D = 3.41
Weight (LBs): 8
Electrical Parameters
| Input Voltage: | 120V 60Hz |
| Max. input current: | 1.5A at full load |
| Output voltage without load: | 12.7VDC |
| Output voltage fully loaded: | 11.5VDC |
| Max. Total Wattage: | 150W |
| Max. Output Current: | 12.5A |
| Efficiency: | 90% |
