Intermatic FD12HWC | Spring Wound Countdown Timer, Decorator Style, 125-277 VAC, 50/60 Hz, SPST, 12 Hour Max, Without Hold - White - Ready Wholesale Electric Supply and Lighting

Intermatic FD12HWC | Spring Wound Countdown Timer, Decorator Style, 125-277 VAC, 50/60 Hz, SPST, 12 Hour Max, Without Hold - White

Intermatic - Outdoor Lighting, Electronic Timer and more | Intermatic Spring Wound Timers | Products |
SKU: FD12HWC

  • Save $33.28

FD12HWC

SPRING WOUND COUNTDOWN TIMER, DECORATOR STYLE, 125-277 VAC, 50/60 HZ, SPST, 12 HOUR MAX, WITHOUT HOLD, WHITE

The FD Series Decorator Countdown Timers are designed to replace any standard or decorator style wall switch, single- or multi-gang. These mechanical timers do not require electricity to operate. They automatically limit the ON times for fans, lighting, motors, heaters and other energy consuming loads.

Features
  • 12-Hour timer
  • SPST (Single-Pole Single-Throw)
  • Breaks circuit at end of timing cycle
  • No electricity required to operate
  • Replaces any standard or decorator single- or multi-gang wall switch
  • Automatically limits ON time for energy consuming loads
  • Quick and easy installation
  • Time-saving up front terminal connection with teeter-type terminals
  • Incandescent/fluorescent/CFL/LED compatible
  • No neutral connection is required
  • Decorator switch plate not included
Applications
  • Bathroom Fans
  • Garage Lights
  • Storage Closets
  • Whirlpools
  • Lights
  • Whole House Fans
Documents & Downloads
C-CSA-US RU



If you don't see the exact model number or color you are looking for, call our Internet Sales Department at 1-818-477-4017. We can get anything for you!
